$17,506.35
Description
Product Description
Printer Type 5-Colour 44-inch
Print Speed 64sq m/hr
Print Head 1.073 FINE (Photolithography Ink-Jet Nozzle Engineering)
Number of Nozzles 15,360
Max Resolution 2400 x 1200 dpi
Minimum Line Width 0.02mm
Ink Droplet 4 picolitre
Colour Set Dye,Cyan, Magenta, Yellow, Black; Pigment Matte Black
Ink Cartridges Capacity 700ml/330ml
Memory 32GB dedicated file processing memory (384MB Physical DRAM)
Hard Drive 160GB
Languages GARD (Canon Proprietary); HP-GL/2; HP RTL
Scanner Specifications
Scan Speed* 24-bit Full Colour @ 200 dpi: 1.67” (per second) 8-bit Grayscale and Monochrome @ 200 dpi: 10” (per second)
Scan Modes 16.7-million colour RGB (24 Bit) 256 and 16 colour RGB adaptive indexed colour palette (8-bit and 4-bit) 256-level Grayscale (8 Bit) Black and White (1 Bit)
Colour Space Normalized RGB
Colour Image Processing Gamma, Brightness, Black-and-White Point Adjustment
Resolution 9600 dpi (maximum) 600 dpi (optical) Variable (100-9600 dpi, in one-dpi steps)
Scan Accuracy** +/- 0.1% ; +/- 1 pixel
Maximum Image Width 40 Inches
Maximum Media Width 41 Inches
Maximum Media Thickness 0.3mm (0.0123)
Media Feed System Single large diameter precision ground drive roller; adaptive CIS media focus mangagement and media guide mechanism; intuitive face-up, front-loading, and front-exit media path with side justification; automatic media size detection with reliable optical media sensors
Digital Imaging Technology
Contact Image Sensor (CIS) Technology 5x close-spaced “deep focus” CIS (17,000 pixels) 5x close-spaced “deep focus” CIS (17,000 pixels) 48-bit RGB digital colour image capture 16-bit grayscale image capture Panchromatic monochrome and black and white Bi-directional extra long-life LED light system for optimum object illumination and instant-on scanning capability
Digital Image Processing
2D Intelligent Adaptive Thresholding (IAT) (1-bit mode) Fixed Threshold Black and White (1-bit mode) Fixed Threshold Black and White (1-bit mode) Dynamic Normalisation Application (DNA) with 16-bit super sampling
User Status and One-Touch Operation
Center mounted LCD scanner control panel; walk-up operation and user selection of scanner mode with stop, forward, rewind, scan, and copy buttons; local language options, and panel overlay
Included Software SmartWorks MFP scan-to-file, copy, e-mail with real-time image viewer.
SmartWorks MFP scan-to-file, copy, e-mail with real-time image viewer. Supports TIFF, JPEG, TIFF G4, and PDF.
Operating System Windows 7
Scanner Interface Kit
USB 2.0 Hi-speed
Operating Environments 10 – 30°C, 35-80% RH, non-condensing
External Power Supply 100-250 VAC autosensing +/- 10%, 50-60 Hz
Scanner Power Consumption 40W (Scanning) 4.2W (Stand-by)
Compliances CB, CE, C-Tick, FCC, UL, RoHS, ENERGY STAR®
MFP Dimensions (H x W x D) (with Monitor) (Does not include Printer) 170 x 145 x 80cm
Package Dimensions (H x W x D) 49 x 145 x 56 cm
Package Weight 88KG
What’s In The Box?
imagePROGRAF Printer CiC40 Scanner with power cord and USB 2.0 Cable (Scanner to Server) CiC40 MFP Stand CiC40 MFP Stand Assembly Instructions SmartWorks MFP Software Dell Computer with Microsoft Windows 7 23” Flat Panel Touch-screen Display Installation and Operation Manual Operator Manual on CD-ROM
